IBPJD3100GN
IBPJD3100GN
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
IBPJD3100GN Specifications
View Full SpecificationsView Specifications
IBPJD3100GN, Eaton, Westinghouse, Cutler Hammer, bus plug, POW-R-WAY I And II, type IBPJD, 3PH, 4W, 600V, 100A, 35kA@480V, , breaker type, complete with JD frame circuit breaker, suitable for use with POW-R-WAY I And II aluminum & copper busway systems
| Manufacturer | Westinghouse | Subcategory | Breaker Type |
| Family | POW-R-WAY I And II | Amperage | 100 |
| Phase | 3 | Wire | 4 |
| Manufacturer | Westinghouse | ||
| Subcategory | Breaker Type | ||
| Family | POW-R-WAY I And II | ||
| Amperage | 100 | ||
| Phase | 3 | ||
| Wire | 4 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
IBPJD3100GN Specifications:
Part NumberIBPJD3100GN
Manufacturers
Sub-CategoryBreaker Type
FamilyPOW-R-WAY I And II
TypeIBPJD
UPC786683009966
Weight65 lbs
Amperage100
Phase3
Wire4
Voltage600
AIC Rating35kA@480V
Suit FrameJD
