- Circuit Breaker /
- Molded Case /
- Merlin Gerin /
24500
24500
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
24500 Specifications
View Full SpecificationsView Specifications
24500, Merlin Gerin, Multi9, C60N, type D, 1P, 1PH, 1A, 277V, 40°C, 5kA@277V, standard interrupting capacity, Feed-Thru, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic molded case circuit breakers
| Manufacturer | Merlin Gerin | Subcategory | Molded Case |
| Family | Multi9 | Amperage | 1 |
| Voltage | 277 | Poles | 1 |
| Manufacturer | Merlin Gerin | ||
| Subcategory | Molded Case | ||
| Family | Multi9 | ||
| Amperage | 1 | ||
| Voltage | 277 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
24500 Specifications:
Part Number24500
Manufacturers
Sub-CategoryMolded Case
FamilyMulti9
Type245
Weight0.24 lbs
Amperage1
Voltage277
Poles1
AIC Rating5kA@277V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Phase1
Additional Information
