28910

Merlin Gerin - Molded Case

Merlin Gerin Molded Case 28910

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

28910 Specifications

View Specifications

28910 Merlin Gerin Interpact, INS125, standard version with black handle, 3P with neutral, 3PH, 125A, 750V, 50/60Hz, IEC rated, 20kA@750V, standard interrupting capacity, Feed-Thru, NA - No Overcurrent Protection, line & load side lug terminals, Non-Automatic molded case switch

Manufacturer
Merlin Gerin
Subcategory
Molded Case
Family
Interpact
Amperage
125
Voltage
750
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
28910 Specifications:
Part Number28910
Manufacturers
Merlin Gerin
Sub-CategoryMolded Case
FamilyInterpact
TypeINS
Weight10 lbs
Amperage125
Voltage750
Poles3
AIC Rating20kA@750V
FunctionsNA - No Overcurrent Protection
ProtectionNon-Automatic
ConnectionFeed-Thru
Phase3
