T5L400E5W

ABB - Molded Case

ABB Molded Case T5L400E5W

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

T5L400E5W Specifications

View Specifications

T5L400E5W, ABB, SACE Tmax, type T5L, 3P, 3PH, 400A, 600V, 100kA@480V, 1200kA@415V, Bolt-On, complete with I - Instantaneous protection only and load side lug terminals, MCP- AC only, motor circuit protectors, magnetic range 400-4000A, Magnetic Only, molded case circuit breakers

Manufacturer
ABB
Subcategory
Molded Case
Family
SACE Tmax
Amperage
400
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
T5L400E5W Specifications:
Part NumberT5L400E5W
Manufacturers
ABB
Sub-CategoryMolded Case
FamilySACE Tmax
TypeT5L
Weight10 lbs
Amperage400
Voltage600
Poles3
AIC Rating100kA@480V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionBolt-On
Frame TypeT5
Phase3
