CH260GFT
CH260GFT
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
CH260GFT Specifications
View Full SpecificationsView Specifications
CH260GFT, Eaton, Cutler Hammer, CH Series, type CH, 1PH, 2P, 120/240V, 60A, 10kA@120/240V, Plug-In, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers
| Manufacturer | Cutler Hammer | Subcategory | Molded Case |
| Family | CH Series | Amperage | 60 |
| Voltage | 240 | Poles | 2 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Molded Case | ||
| Family | CH Series | ||
| Amperage | 60 | ||
| Voltage | 240 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
CH260GFT Specifications:
Part NumberCH260GFT
Manufacturers
Sub-CategoryMolded Case
FamilyCH Series
TypeCH
UPC786676025669
Weight0.7 lbs
Amperage60
Voltage240
Poles2
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Frame TypeCH Frame
Phase1
Additional Information
