E2LE3600MW Cutler Hammer 600A 3P Series C Molded Case Circuit Breaker

E2LE3600MW

Cutler Hammer - Molded Case

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

E2LE3600MW Specifications

View Full SpecificationsView Specifications

E2LE3600MW, Cutler Hammer, Series C, E2 mining service breakers, type E2LE, 3P, 3PH, 600A, 600V, 25kA@480V, standard interrupting capacity, Bolt-On, complete with interchangeable trip, I - Instantaneous trip functions, magnetic range 500-2500A, lugs not included, Solid State electronic, molded case circuit breakers

Manufacturer	Cutler Hammer	Subcategory	Molded Case
Family	Series C	Amperage	600
Voltage	600	Poles	3
Manufacturer	Cutler Hammer
Subcategory	Molded Case
Family	Series C
Amperage	600
Voltage	600
Poles	3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

E2LE3600MW Specifications:

Part NumberE2LE3600MW

Manufacturers

Cutler Hammer

Sub-CategoryMolded Case

FamilySeries C

TypeE2LE

Weight25 lbs

Amperage600

Voltage600

Poles3

AIC Rating25kA@480V
