E3045VL Cutler Hammer 45A 3P E Series Molded Case Circuit Breaker

E3045VL

Cutler Hammer - Molded Case

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

E3045VL Specifications

View Full SpecificationsView Specifications

E3045VL, Cutler Hammer, E Series, type E, 3P, 3PH, 45A, 240V, 7kA@240V, standard interrupting capacity, 50°C, Feed-Thru, complete with LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are now obsolete; however, we do still stock them

Manufacturer	Cutler Hammer	Subcategory	Molded Case
Family	E Series	Amperage	45
Voltage	240	Poles	3
Manufacturer	Cutler Hammer
Subcategory	Molded Case
Family	E Series
Amperage	45
Voltage	240
Poles	3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

E3045VL Specifications:

Part NumberE3045VL

Manufacturers

Cutler Hammer

Sub-CategoryMolded Case

FamilyE Series

TypeE

Weight7 lbs

Amperage45

Voltage240

Poles3

AIC Rating7kA@240V
