FS220080A

Cutler Hammer - Molded Case

Cutler Hammer Molded Case FS220080A

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FS220080A Specifications

View Specifications

FS220080A, Cutler Hammer, FS Series, type FS, 2P, 1PH, 80A, 240V, 40°C, 22kA@240V, standard interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, line & load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we still stock them

Manufacturer
Cutler Hammer
Subcategory
Molded Case
Family
FS Series
Amperage
80
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FS220080A Specifications:
Part NumberFS220080A
Manufacturers
Cutler Hammer
Sub-CategoryMolded Case
FamilyFS Series
TypeFS
Weight3 lbs
Amperage80
Voltage240
Poles2
AIC Rating22kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Phase1
