GD3080 Cutler Hammer 80A 3P Series C Molded Case Circuit Breaker

GD3080

Cutler Hammer - Molded Case

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

GD3080 Specifications

View Full SpecificationsView Specifications

GD3080, Westinghouse, Eaton, Cutler Hammer, Series C, type GD, 3P, 3PH, 80A, 480V, 22kA@480V, standard interrupting capacity, 40°C, Feed-Thru, suitable for reverse feed use, complete with non-interchangeable LI, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer	Cutler Hammer	Subcategory	Molded Case
Family	Series C	Amperage	80
Voltage	480	Poles	3
Manufacturer	Cutler Hammer
Subcategory	Molded Case
Family	Series C
Amperage	80
Voltage	480
Poles	3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

GD3080 Specifications:

Part NumberGD3080

Manufacturers

Westinghouse, Eaton, Cutler Hammer

Sub-CategoryMolded Case

FamilySeries C

TypeGD

UPC786679231203

Weight2.1 lbs

Amperage80

Voltage480

Poles3
