HKB3175 Cutler Hammer 175A 3P MARK 75 Molded Case Circuit Breaker

HKB3175

Cutler Hammer - Molded Case

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

HKB3175 Specifications

View Full SpecificationsView Specifications

HKB3175, Cutler Hammer, Westinghouse, MARK 75, type HKB, 3P, 3PH, 175A, 600V, 25kA@480V, high interrupting capacity, Bolt-On, complete with interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete, however we do still stock them

Manufacturer	Cutler Hammer	Subcategory	Molded Case
Family	MARK 75	Amperage	175
Voltage	600	Poles	3
Manufacturer	Cutler Hammer
Subcategory	Molded Case
Family	MARK 75
Amperage	175
Voltage	600
Poles	3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

HKB3175 Specifications:

Part NumberHKB3175

Manufacturers

Cutler Hammer, Westinghouse

Sub-CategoryMolded Case

FamilyMARK 75

TypeHKB

Weight19 lbs

Amperage175

Voltage600

Poles3

AIC Rating25kA@480V
