HMCPE100T3C
HMCPE100T3C
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HMCPE100T3C Specifications
View Full SpecificationsView Specifications
HMCPE100T3C, Cutler Hammer, Series G, type HMCPE, EG Frame, 3P, 3PH, 100A, 480V, 600Y/347Vac, 40°C, Feed-Thru, complete with non-interchangeable trip with I - Instantaneous protection only, non-aluminum line & load side lug terminals, MCP, motor circuit protector, magnetic range 500-1500A, motor FLA 38.0-84.5A, Magnetic Only, molded case circuit breakers
| Manufacturer | Cutler Hammer | Subcategory | Molded Case |
| Family | Series G | Amperage | 100 |
| Voltage | 480 | Poles | 3 |
| Manufacturer | Cutler Hammer | ||
| Subcategory | Molded Case | ||
| Family | Series G | ||
| Amperage | 100 | ||
| Voltage | 480 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HMCPE100T3C Specifications:
Part NumberHMCPE100T3C
Manufacturers
Sub-CategoryMolded Case
FamilySeries G
TypeHMCPE
Weight3 lbs
Amperage100
Voltage480
Poles3
AIC Rating15kA@400V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Phase3
