JGSDC3150FAW

Cutler Hammer - Molded Case

Cutler Hammer Molded Case JGSDC3150FAW

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

JGSDC3150FAW Specifications

View Specifications

JGSDC3150FAW, Cutler Hammer, Series G, type JGSDC, 3P, 3PH, 150A, 600V, DC rated, 50kA@600V, standard interrupting capacity, Bolt-On, complete with trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers

Manufacturer
Cutler Hammer
Subcategory
Molded Case
Family
Series G
Amperage
150
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
JGSDC3150FAW Specifications:
Part NumberJGSDC3150FAW
Manufacturers
Cutler Hammer
Sub-CategoryMolded Case
FamilySeries G
TypeJGSDC
Weight13 lbs
Amperage150
Voltage600
Poles3
AIC Rating50kA@600V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
