BRH280
BRH280
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
BRH280 Specifications
View Full SpecificationsView Specifications
BRH280, Eaton, Cutler Hammer, BR Series, type BRH, 2P, 1PH, 80A, 120/240V, 22kA@240V, high interrupting capacity, 40ºC, Plug-In, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | BR Series | Amperage | 80 |
| Voltage | 240 | Poles | 2 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | BR Series | ||
| Amperage | 80 | ||
| Voltage | 240 | ||
| Poles | 2 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
BRH280 Specifications:
Part NumberBRH280
Manufacturers
Sub-CategoryMolded Case
FamilyBR Series
TypeBRH
UPC782114372180
Weight0.6 lbs
Amperage80
Voltage240
Poles2
AIC Rating22kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Phase1
