CCV2175W

Eaton - Molded Case

Eaton Molded Case CCV2175W

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

CCV2175W Specifications

View Specifications

CCV2175W, Eaton, Cutler Hammer, Tenant Main, type CCV, 2P, 1PH, 175A, 120/240V, 10kA@240V, UL listed, standard interrupting capacity, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions, lugs not included, suitable for use as tenant main circuit breaker, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Tenant Main
Amperage
175
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
CCV2175W Specifications:
Part NumberCCV2175W
Manufacturers
Eaton, Cutler Hammer
Sub-CategoryMolded Case
FamilyTenant Main
TypeCCV
Weight2 lbs
Amperage175
Voltage240
Poles2
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
