- Circuit Breaker /
- Molded Case /
- Eaton /
CH360
CH360
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
CH360 Specifications
View Full SpecificationsView Specifications
CH360, Cutler Hammer, Eaton, CH Series, type CH, 3P, 3PH, 60A, 240V, 10kA@240V, standard interrupting capacity, 40ºC, Plug-In, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | CH Series | Amperage | 60 |
| Voltage | 240 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | CH Series | ||
| Amperage | 60 | ||
| Voltage | 240 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
CH360 Specifications:
Part NumberCH360
Manufacturers
Sub-CategoryMolded Case
FamilyCH Series
TypeCH
UPC782113102115
Weight1 lbs
Amperage60
Voltage240
Poles3
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionPlug-In
Frame TypeCH Frame
Phase3
Additional Information
