EDC2200Y

Eaton - Molded Case

Eaton Molded Case EDC2200Y

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

EDC2200Y Specifications

View Specifications

EDC2200Y, Westinghouse, Cutler Hammer, Eaton, Series C, type EDC, 2P, 2PH, 200A, 240V, 200kA@240V, current limiting, 40ºC, Bolt-On, suitable for reverse fed applications, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
200
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
EDC2200Y Specifications:
Part NumberEDC2200Y
Manufacturers
Westinghouse, Cutler Hammer, Eaton
Sub-CategoryMolded Case
FamilySeries C
TypeEDC
UPC786679455906
Weight3 lbs
Amperage200
Voltage240
Poles2
AIC Rating200kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
TerminalsLine only
ConnectionBolt-On
Frame TypeF Frame
Phase2
