- Circuit Breaker /
- Molded Case /
- Eaton /
EGEDC3090FFW
EGEDC3090FFW
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
EGEDC3090FFW Specifications
View Full SpecificationsView Specifications
EGEDC3090FFW, Eaton, Cutler Hammer, Series G, type EGEDC, 3P, 3PH, 90A, 600V, DC rated, 35kA@500V, high interrupting capacity, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions, lugs not included, Thermal Magnetic molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series G | Amperage | 90 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series G | ||
| Amperage | 90 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
EGEDC3090FFW Specifications:
Part NumberEGEDC3090FFW
Manufacturers
Sub-CategoryMolded Case
FamilySeries G
TypeEGEDC
Weight3 lbs
Amperage90
Voltage600
Poles3
AIC Rating35kA@500V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
Additional Information
