1. Circuit Breaker /
  2. Molded Case /
  3. Eaton /

    4. EHD2035L

EHD2035L

Eaton - Molded Case

Eaton Molded Case EHD2035L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

EHD2035L Specifications

View Specifications

EHD2035L, Eaton, Westinghouse, Cutler Hammer, Series C, type EHD, 2P, 1PH, 35A, 480V, 14kA@480V, standard interrupting capacity, 40°C, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
35
Voltage
480
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
EHD2035L Specifications:
Part NumberEHD2035L
Manufacturers
Eaton, Westinghouse, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries C
TypeEHD
UPC786679850879
Weight3 lbs
Amperage35
Voltage480
Poles2
AIC Rating14kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
TerminalsLine and load
ConnectionFeed-Thru
Frame TypeF Frame
Phase1
