EHD3030S05

Eaton - Molded Case

Eaton Molded Case EHD3030S05

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

EHD3030S05 Specifications

View Specifications

EHD3030S05, Cutler Hammer, Eaton, Series C, type EHD, 3P, 3PH, 30A, 480V, 14kA@480V, standard interrupting capacity, 40°C, Bolt-On, complete with 48-127Vac/48-60Vdc shunt trip, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
30
Voltage
480
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
EHD3030S05 Specifications:
Part NumberEHD3030S05
Manufacturers
Cutler Hammer, Eaton
Sub-CategoryMolded Case
FamilySeries C
TypeEHD
UPC786679051948
Weight4.5 lbs
Amperage30
Voltage480
Poles3
AIC Rating14kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
Shunt Trip48-127 Vac Left Pole Mount
ConnectionBolt-On
Frame TypeF Frame
Phase3
