EL4FD3125L

Eaton - Molded Case

Eaton Molded Case EL4FD3125L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

EL4FD3125L Specifications

View Specifications

EL4FD3125L, Westinghouse, Cutler Hammer, Eaton, Series C, type 3L4FD, 4P, 3PH, 125A, 600V, 35kA@480V, standard interrupting capacity, 40ºC, Feed-Thru, complete with Eath Leakage module, non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
125
Voltage
600
Poles
4

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
EL4FD3125L Specifications:
Part NumberEL4FD3125L
Manufacturers
Westinghouse, Cutler Hammer, Eaton
Sub-CategoryMolded Case
FamilySeries C
Type3L4FD
Weight3 lbs
Amperage125
Voltage600
Poles4
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Phase3
