FD1040

Eaton - Molded Case

Eaton Molded Case FD1040

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FD1040 Specifications

View Specifications

FD1040, Eaton, Westinghouse, Cutler Hammer, Series C, type FD, 1P, 1PH, 40A, 277V, 35kA@277V, standard interrupting capacity, 40°C, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
40
Voltage
277
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FD1040 Specifications:
Part NumberFD1040
Manufacturers
Eaton, Westinghouse, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries C
TypeFD
UPC786679312148
Weight4.5 lbs
Amperage40
Voltage277
Poles1
AIC Rating35kA@277V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeF Frame
Phase1
