GD2035D

Eaton - Molded Case

Eaton Molded Case GD2035D

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

GD2035D Specifications

View Specifications

GD2035D, Westinghouse, Cutler Hammer, Eaton, Series C, type GD, 2P, 1PH, 35A, 480V, 22kA@480V, standard interrupting capacity, 40°C, Feed-Thru, suitable for reverse feed use, complete with non-interchangeable LI, LI - Long-Time and Instantaneous trip functions and ring type line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
35
Voltage
480
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
GD2035D Specifications:
Part NumberGD2035D
Manufacturers
Westinghouse, Cutler Hammer, Eaton
Sub-CategoryMolded Case
FamilySeries C
TypeGD
UPC782116165292
Weight1.25 lbs
Amperage35
Voltage480
Poles2
AIC Rating22kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeG Frame
Phase1
