GHB1030I

Eaton - Molded Case

Eaton Molded Case GHB1030I

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

GHB1030I Specifications

View Specifications

GHB1030I, Eaton, Westinghouse, Cutler Hammer, Series C, type GHB, 1P, 1PH, 30A, 277/480V, 125VDC, 14kA@277V, standard interrupting capacity, 40°C, Bolt-On, suitable for reverse feed use, complete with non-interchangeable, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
30
Voltage
480
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
GHB1030I Specifications:
Part NumberGHB1030I
Manufacturers
Eaton, Westinghouse, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries C
TypeGHB
UPC782114313497
Weight0.54 lbs
Amperage30
Voltage480
Poles1
AIC Rating14kA@277V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeG Frame
Phase1
