GHB2070I

Eaton - Molded Case

Eaton Molded Case GHB2070I

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

GHB2070I Specifications

View Specifications

GHB2070I, Eaton, Westinghouse, Cutler Hammer, Series C, Type GHB, 2P, 1PH, 70A, 277/480V,125/250VDC, 14kA@480V, standard interrupting capacity, 40°C, Bolt-On, suitable for reverse feed use, complete with non-interchangeable, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
70
Voltage
480
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
GHB2070I Specifications:
Part NumberGHB2070I
Manufacturers
Eaton, Westinghouse, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries C
TypeGHB
UPC782114313695
Weight1.5 lbs
Amperage70
Voltage480
Poles2
AIC Rating14kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeG Frame
Phase1
