1. Circuit Breaker /
  2. Molded Case /
  3. Eaton /

    4. HFD2045L

HFD2045L

Eaton - Molded Case

Eaton Molded Case HFD2045L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HFD2045L Specifications

View Specifications

HFD2045L, Eaton, Westinghouse, Cutler Hammer, Series C, type HFD, 2P, 1PH, 45A, 600V, 65kA@480V, high interrupting capacity, 40℃, Feed-Thru, complete with non-interchangeable, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
45
Voltage
600
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HFD2045L Specifications:
Part NumberHFD2045L
Manufacturers
Eaton, Westinghouse, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries C
TypeHFD
UPC786679283387
Weight4.5 lbs
Amperage45
Voltage600
Poles2
AIC Rating65kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
TerminalsLine and load
ConnectionFeed-Thru
Frame TypeF Frame
Phase1
