HFDDC3045L

Eaton - Molded Case

Eaton Molded Case HFDDC3045L

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HFDDC3045L Specifications

View Specifications

HFDDC3045L, Cutler Hammer, Eaton, Westinghouse, Series C, type HFDDC, 3P, 3PH, 45A, 600V, DC rated, 42kA@600V, high interrupting capacity, Feed-Thru, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
45
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HFDDC3045L Specifications:
Part NumberHFDDC3045L
Manufacturers
Cutler Hammer, Eaton, Westinghouse
Sub-CategoryMolded Case
FamilySeries C
TypeHFDDC
Weight4 lbs
Amperage45
Voltage600
Poles3
AIC Rating42kA@600V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeF Frame
Phase3
