HFDE308036
HFDE308036
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HFDE308036 Specifications
View Full SpecificationsView Specifications
HFDE308036, Westinghouse, Cutler Hammer, Eaton, Series C, type HFDE, 3P, 3PH, 80A, 480V, 65kA@480V, high interrupting capacity, Bolt-On, complete with LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault trip functions and load side lug terminals, Solid State electronic, molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series C | Amperage | 80 |
| Voltage | 480 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series C | ||
| Amperage | 80 | ||
| Voltage | 480 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HFDE308036 Specifications:
Part NumberHFDE308036
Manufacturers
Sub-CategoryMolded Case
FamilySeries C
TypeHFDE
UPC786685112695
Weight4.5 lbs
Amperage80
Voltage480
Poles3
AIC Rating65kA@480V
FunctionsLSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
ProtectionSolid State
TerminalsLoad side only
ConnectionBolt-On
Frame TypeF Frame
Phase3
