HGHB1020
HGHB1020
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HGHB1020 Specifications
View Full SpecificationsView Specifications
HGHB1020, Eaton, Westinghouse, Cutler Hammer, Series C, Type HGHB, LI - Long-Time and Instantaneous, Feed-Thru, Thermal Magnetic, G Frame, 25kA@277V, 20A, 277V, 1PH, 1P, molded case, circuit breaker
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series C | Amperage | 20 |
| Voltage | 277 | Poles | 1 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series C | ||
| Amperage | 20 | ||
| Voltage | 277 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HGHB1020 Specifications:
Part NumberHGHB1020
Manufacturers
Sub-CategoryMolded Case
FamilySeries C
TypeHGHB
UPC786679114186
Weight0.67 lbs
Amperage20
Voltage277
Poles1
AIC Rating25kA@277V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeG Frame
Phase1
