HMCPE003A0C
HMCPE003A0C
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HMCPE003A0C Specifications
View Full SpecificationsView Specifications
HMCPE003A0C, Eaton, Cutler Hammer, Series G, type HMCPE, EG Frame, 3P, 3PH, 3A, 480V, 600Y/347Vac, 40°C, Feed-Thru, complete with non-interchangeable trip with I - Instantaneous protection only, non-aluminum line & load side lug terminals, MCP, motor circuit protector, magnetic range 9-33A, motor FLA 0.69-2.8A, Magnetic Only, molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series G | Amperage | 3 |
| Voltage | 480 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series G | ||
| Amperage | 3 | ||
| Voltage | 480 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HMCPE003A0C Specifications:
Part NumberHMCPE003A0C
Manufacturers
Sub-CategoryMolded Case
FamilySeries G
TypeHMCPE
UPC786679113639
Weight3 lbs
Amperage3
Voltage480
Poles3
AIC Rating15kA@400V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Phase3
