HMCPE050K2C

Eaton - Molded Case

Eaton Molded Case HMCPE050K2C

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

HMCPE050K2C Specifications

View Specifications

HMCPE050K2C, Eaton, Cutler Hammer, Series G, type HMCPE, EG Frame, 3P, 3PH, 50A, 480V, 600Y/347Vac, 40°C, Feed-Thru, complete with non-interchangeable trip with I - Instantaneous protection only, non-aluminum line & load side lug terminals, MCP, motor circuit protector, magnetic range 150-550A, motor FLA 11.5-43.5A, Magnetic Only, molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series G
Amperage
50
Voltage
480
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
HMCPE050K2C Specifications:
Part NumberHMCPE050K2C
Manufacturers
Eaton, Cutler Hammer
Sub-CategoryMolded Case
FamilySeries G
TypeHMCPE
UPC786679113677
Weight2.6 lbs
Amperage50
Voltage480
Poles3
AIC Rating15kA@400V
FunctionsI - Instantaneous
ProtectionMagnetic Only
ConnectionFeed-Thru
Phase3
