- Circuit Breaker /
- Molded Case /
- Eaton /
JD3250KW
JD3250KW
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
JD3250KW Specifications
View Full SpecificationsView Specifications
JD3250KW, Eaton, Westinghouse, Cutler Hammer, Series C, type JD, 3PH, 3P, 600V, 250A, 35kA@480V, Bolt-On, complete with NA - No Overcurrent Protection trip functions, Non-Automatic, molded case circuit breaker
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series C | Amperage | 250 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series C | ||
| Amperage | 250 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
JD3250KW Specifications:
Part NumberJD3250KW
Manufacturers
Sub-CategoryMolded Case
FamilySeries C
TypeJD
UPC786679516454
Weight9.55 lbs
Amperage250
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsNA - No Overcurrent Protection
ProtectionNon-Automatic
ConnectionBolt-On
Frame TypeJ Frame
Phase3
