LD3450

Eaton - Molded Case

Eaton Molded Case LD3450

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

LD3450 Specifications

View Specifications

LD3450, Cutler Hammer, Westinghouse, Eaton, Series C, type LD, 3P, 3PH, 450A, 600V, 35kA@480V, standard interrupting capacity, 40°C, Feed-Thru, complete with interchangeable LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
Series C
Amperage
450
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
LD3450 Specifications:
Part NumberLD3450
Manufacturers
Cutler Hammer, Westinghouse, Eaton
Sub-CategoryMolded Case
FamilySeries C
TypeLD
UPC786679015612
Weight21 lbs
Amperage450
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Frame TypeL Frame
Phase3
