LW3630WK
LW3630WK
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
LW3630WK Specifications
View Full SpecificationsView Specifications
LW3630WK, Cutler Hammer, Eaton, Westinghouse, Series C, type LW, 3P, 3PH, 630A, 690V, 40kA@415V, IEC rated, standard interrupting capacity, Bolt-On, lugs not included, NA - No Overcurrent Protection, Non-Automatic, molded case switch, molded case circuit breakers
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series C | Amperage | 630 |
| Voltage | 690 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series C | ||
| Amperage | 630 | ||
| Voltage | 690 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
LW3630WK Specifications:
Part NumberLW3630WK
Manufacturers
Sub-CategoryMolded Case
FamilySeries C
TypeLW
UPC786679003008
Weight20 lbs
Amperage630
Voltage690
Poles3
AIC Rating40kA@415V
FunctionsNA - No Overcurrent Protection
ProtectionNon-Automatic
ConnectionBolt-On
Frame TypeL Frame
Phase3
