MDL3800F
MDL3800F
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
MDL3800F Specifications
View Full SpecificationsView Specifications
MDL3800F, Eaton, Westinghouse, Cutler Hammer, Series C, type MDL, 3PH, 3P, 600V, 800A, 50kA@480V, Bolt-On, complete with LSI - Long-Time, Short-Time and Instantaneous trip functions, Thermal Magnetic, molded case circuit breaker - FRAME ONLY
| Manufacturer | Eaton | Subcategory | Molded Case |
| Family | Series C | Amperage | 800 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | Eaton | ||
| Subcategory | Molded Case | ||
| Family | Series C | ||
| Amperage | 800 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
MDL3800F Specifications:
Part NumberMDL3800F
Manufacturers
Sub-CategoryMolded Case
FamilySeries C
TypeMDL
UPC782114350577
Weight26.2 lbs
Amperage800
Voltage600
Poles3
AIC Rating50kA@480V
FunctionsLSI - Long-Time, Short-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Frame TypeM Frame
Phase3
