1. Circuit Breaker /
  2. Molded Case /
  3. Eaton /

    4. WMZT3C02

WMZT3C02

Eaton - Molded Case

Eaton Molded Case WMZT3C02

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

WMZT3C02 Specifications

View Specifications

WMZT3C02, Eaton, WMZ Series, type WMZT, 3P, 3PH, 2A, 277/480V, 10kA@480V, C curve, standard interrupting capacity, Feed-Thru, standard box terminals, suitable for reverse feed, UL/CSA approval, branch circuit protection, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, din rail mounted, miniature molded case circuit breakers

Manufacturer
Eaton
Subcategory
Molded Case
Family
WMZ Series
Amperage
2
Voltage
480
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
WMZT3C02 Specifications:
Part NumberWMZT3C02
Manufacturers
Eaton
Sub-CategoryMolded Case
Other NamesWMZT-3C02
FamilyWMZ Series
TypeWMZT
UPC786685257518
Weight0.86 lbs
Amperage2
Voltage480
Poles3
AIC Rating10kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionFeed-Thru
Phase3
