EP103ULD40

General Electric - Molded Case

General Electric Molded Case EP103ULD40

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

EP103ULD40 Specifications

View Specifications

EP103ULD40, General Electric, Redline, Series EP100, 686993, UL 1077 approval, D tripping, 3P, 3PH, 40A, 277/480V, 10kA@277V/480V, Bolt-On, LI - Long-Time and Instantaneous trip functions, Thermal Magnetic, molded case miniature circuit breakers

Manufacturer
General Electric
Subcategory
Molded Case
Family
Redline
Amperage
40
Voltage
480
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
EP103ULD40 Specifications:
Part NumberEP103ULD40
Manufacturers
General Electric
Sub-CategoryMolded Case
FamilyRedline
TypeEP100
UPC413656869936
Amperage40
Voltage480
Poles3
AIC Rating10kA@277V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
