FBL16TE030R

General Electric - Molded Case

General Electric Molded Case FBL16TE030R

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FBL16TE030R Specifications

View Specifications

FBL16TE030R General Electric Record Plus, type FBL, FB100 frame, 1P, 1PH, 30A, 600V, 150kA@240V, current limiting, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions, lugs not included, fixed Thermal Magnetic, molded case circuit breakers

Manufacturer
General Electric
Subcategory
Molded Case
Family
Record Plus
Amperage
30
Voltage
600
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FBL16TE030R Specifications:
Part NumberFBL16TE030R
Manufacturers
General Electric
Sub-CategoryMolded Case
FamilyRecord Plus
TypeFBL
Weight1 lbs
Amperage30
Voltage600
Poles1
AIC Rating150kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
