FBV16TE060RV
FBV16TE060RV
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
FBV16TE060RV Specifications
View Full SpecificationsView Specifications
FBV16TE060RV General Electric Record Plus, type FBV, FB100 frame, 1P, 1PH, 60A, 600V, 150kA@480V, standard interrupting capacity, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals and panel connections, fixed Thermal Magnetic, molded case circuit breakers
| Manufacturer | General Electric | Subcategory | Molded Case |
| Family | Record Plus | Amperage | 60 |
| Voltage | 600 | Poles | 1 |
| Manufacturer | General Electric | ||
| Subcategory | Molded Case | ||
| Family | Record Plus | ||
| Amperage | 60 | ||
| Voltage | 600 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
FBV16TE060RV Specifications:
Part NumberFBV16TE060RV
Manufacturers
Sub-CategoryMolded Case
FamilyRecord Plus
TypeFBV
UPC783164394030
Weight1 lbs
Amperage60
Voltage600
Poles1
AIC Rating150kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
Additional Information
