FCL326TE025R2

General Electric - Molded Case

General Electric Molded Case FCL326TE025R2

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FCL326TE025R2 Specifications

View Specifications

FCL326TE025R2 General Electric Record Plus, type FCL, FC100 frame, 2P in 3P envelope, 1PH, 25A, 600V, 150kA@480V, current limiting, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, fixed Thermal Magnetic, molded case circuit breakers

Manufacturer
General Electric
Subcategory
Molded Case
Family
Record Plus
Amperage
25
Voltage
600
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FCL326TE025R2 Specifications:
Part NumberFCL326TE025R2
Manufacturers
General Electric
Sub-CategoryMolded Case
FamilyRecord Plus
TypeFCL
Weight3 lbs
Amperage25
Voltage600
Poles2
AIC Rating150kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
