FCV36TE035R2

General Electric - Molded Case

General Electric Molded Case FCV36TE035R2

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

FCV36TE035R2 Specifications

View Specifications

FCV36TE035R2 General Electric Record Plus, type FCV, FC100 frame, 3P, 3PH, 35A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions and load side lug terminals, fixed Thermal Magnetic, molded case circuit breakers

Manufacturer
General Electric
Subcategory
Molded Case
Family
Record Plus
Amperage
35
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
FCV36TE035R2 Specifications:
Part NumberFCV36TE035R2
Manufacturers
General Electric
Sub-CategoryMolded Case
FamilyRecord Plus
TypeFCV
Weight4 lbs
Amperage35
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
