- Circuit Breaker /
- Molded Case /
- General Electric /
SKHH36BB0800
SKHH36BB0800
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
SKHH36BB0800 Specifications
View Full SpecificationsView Specifications
SKHH36BB0800, General Electric, Spectra RMS, type SKHH, 3P, 3PH, 800A, 600V, 50kA@480V, standard interrupting capacity, 100% rated, Bolt-On, suitable for reverse fed applications, UL listed, complete with interchangeable MVT, MicroVersaTrip, Plus trip unit with LSIT - Long-Time, Short-Time, Instantaneous and Targets trip functions, lugs not included, Solid State Electronic, molded case circuit breakers
| Manufacturer | General Electric | Subcategory | Molded Case |
| Family | Spectra RMS | Amperage | 800 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | General Electric | ||
| Subcategory | Molded Case | ||
| Family | Spectra RMS | ||
| Amperage | 800 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
