TEY335AS1A

General Electric - Molded Case

General Electric Molded Case TEY335AS1A

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

TEY335AS1A Specifications

View Specifications

TEY335AS1A, General Electric, Q-Line, type TEY, 3P, 3PH, 35A, 277/480V, 14kA@480V, standard interrupting capacity, 40°C, Bolt-On, with factory installed N.O. Auxiliary switch, Thermal Magnetic molded case circuit breakers

Manufacturer
General Electric
Subcategory
Molded Case
Family
Q-Line
Amperage
35
Voltage
480
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
TEY335AS1A Specifications:
Part NumberTEY335AS1A
Manufacturers
General Electric
Sub-CategoryMolded Case
FamilyQ-Line
TypeTEY
Weight1 lbs
Amperage35
Voltage480
Poles3
AIC Rating14kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
