TP9VT20HLGA3
TP9VT20HLGA3
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
TP9VT20HLGA3 Specifications
View Full SpecificationsView Specifications
TP9VT20HLGA3, General Electric, MicroVersaTrip 9, type TP9VT, trip units and programmers, 200A current sensor rating, 600V, Solid State electronic, LSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault + Targets trip functions, suitable for use with Power Break I TPVF,TPVVF,THPVF,THPVVF 800-2000A frame insulated case circuit breakers
| Manufacturer | General Electric | Subcategory | Trip Units And Programmers |
| Family | MicroVersaTrip 9 | Suit Frame | TPVF,TPVVF,THPVF,THPVVF |
| Voltage | 600 | ||
| Manufacturer | General Electric | ||
| Subcategory | Trip Units And Programmers | ||
| Family | MicroVersaTrip 9 | ||
| Suit Frame | TPVF,TPVVF,THPVF,THPVVF | ||
| Voltage | 600 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
TP9VT20HLGA3 Specifications:
Part NumberTP9VT20HLGA3
Manufacturers
Sub-CategoryTrip Units And Programmers
FamilyMicroVersaTrip 9
TypeTP9VT
Weight2 lbs
Suit FrameTPVF,TPVVF,THPVF,THPVVF
Voltage600
ProtectionSolid State
Poles3
FunctionsLSHG - Long-Time, Short-Time, High-Range Instantaneous and Ground Fault
Amperage Min200
Amperage Max2000
