TXQL1125 General Electric 25A 1P Q-Line Molded Case Circuit Breaker

TXQL1125

General Electric - Molded Case

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

What's the difference?View Specifications

TXQL1125 Specifications

View Full SpecificationsView Specifications

TXQL1125, General Electric, type TXQL, 1P, 1PH, 25A, 120V/240V, 65kA@120V, 40ºC, UL listed, Feed-Thru, Thermal Magnetic, LI - Long-Time and Instantaneous trip functions and line & load side lug terminal, molded case circuit breaker

Manufacturer	General Electric	Subcategory	Molded Case
Family	Q-Line	Amperage	25
Voltage	120	Poles	1
Manufacturer	General Electric
Subcategory	Molded Case
Family	Q-Line
Amperage	25
Voltage	120
Poles	1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

TXQL1125 Specifications:

Part NumberTXQL1125

Manufacturers

General Electric

Sub-CategoryMolded Case

FamilyQ-Line

TypeTXQL

Amperage25

Voltage120

Poles1

AIC Rating65kA@120V

FunctionsLI - Long-Time and Instantaneous
