- Circuit Breaker /
- Molded Case /
- ITE /
HE63B040
HE63B040
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
HE63B040 Specifications
View Full SpecificationsView Specifications
HE63B040, ITE, Siemens, HE Series, type HE, 3P 3PH 40A 600V, 30kA@480V, high interrupting capacity, 40?C, Bolt-On, complete with load side lug terminals, Thermal Magnetic, molded case circuit breakers
| Manufacturer | ITE | Subcategory | Molded Case |
| Family | HE Series | Amperage | 40 |
| Voltage | 600 | Poles | 3 |
| Manufacturer | ITE | ||
| Subcategory | Molded Case | ||
| Family | HE Series | ||
| Amperage | 40 | ||
| Voltage | 600 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
HE63B040 Specifications:
Part NumberHE63B040
Sub-CategoryMolded Case
FamilyHE Series
TypeHE
Weight7 lbs
Amperage40
Voltage600
Poles3
AIC Rating30kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
Additional Information
