    4. LJ63B500

LJ63B500

ITE - Molded Case

|

1 Reviews

ITE Molded Case LJ63B500

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

LJ63B500 Specifications

View Specifications

LJ63B500, ITE, Siemens, LJ Series, type LJ, 3P, 3PH, 500A, 600V, 35kA@480V, standard interrupting capacity, Bolt-On, 40? C, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic, molded case circuit breakers; these breakers are obsolete, however I still stock them

Manufacturer
ITE
Subcategory
Molded Case
Family
LJ Series
Amperage
500
Voltage
600
Poles
3

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
LJ63B500 Specifications:
Part NumberLJ63B500
Manufacturers
ITE, Siemens
Sub-CategoryMolded Case
FamilyLJ Series
TypeLJ
Weight25 lbs
Amperage500
Voltage600
Poles3
AIC Rating35kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
