QJ2B080

ITE - Molded Case

ITE Molded Case QJ2B080

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

QJ2B080 Specifications

View Specifications

QJ2B080, ITE, Siemens, QJ Series, type QJ, 2P, 1PH, 80A, 240V, 10kA@240V, standard interrupting capacity, Bolt-On, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side lug terminals, Thermal Magnetic molded case circuit breakers; these breakers are obsolete however we still stock them

Manufacturer
ITE
Subcategory
Molded Case
Family
QJ Series
Amperage
80
Voltage
240
Poles
2

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
QJ2B080 Specifications:
Part NumberQJ2B080
Manufacturers
ITE, Siemens
Sub-CategoryMolded Case
FamilyQJ Series
TypeQJ
Weight3 lbs
Amperage80
Voltage240
Poles2
AIC Rating10kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase1
