BGA160303

Schneider Electric - Molded Case

Schneider Electric Molded Case BGA160303

IMAGES ARE FOR REFERENCE ONLY.

Select Product Condition:

View Specifications

BGA160303 Specifications

View Specifications

BGA160303, Schneider Electric, Square D, PowerPact, type BGA, 1PH, 1P, 600Y/347Vac, 30A, 65kA@240V, I-Line Style Plug-In with B phase connection, complete with non-interchangeable trip, LI - Long-Time and Instantaneous trip functions and load side mechanical lug terminals, Thermal Magnetic, molded case circuit breakers

Manufacturer
Schneider Electric
Subcategory
Molded Case
Family
PowerPact
Amperage
30
Voltage
600
Poles
1

Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.

Pearl Logo
Standard Warranty Logo
Ships WorldWide Logo
Rush Shipping Logo
BGA160303 Specifications:
Part NumberBGA160303
Manufacturers
Schneider Electric, Square D
Sub-CategoryMolded Case
FamilyPowerPact
TypeBGA
UPC3606481153388
Weight1 lbs
Amperage30
Voltage600
Poles1
AIC Rating65kA@240V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionI-Line Style Plug-In
Frame TypeB Frame
Phase1
