EDB34090
EDB34090
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
EDB34090 Specifications
View Full SpecificationsView Specifications
EDB34090, Schneider Electric, Square D circuit breaker molded case EDB Series, type EDB, 3PH, 3P, 480V, 90A, 18kA@480V, Bolt-On, complete with LI - Long-Time and Instantaneous trip functions, Thermal Magnetic
| Manufacturer | Schneider Electric | Subcategory | Molded Case |
| Family | EDB Series | Amperage | 90 |
| Voltage | 480 | Poles | 3 |
| Manufacturer | Schneider Electric | ||
| Subcategory | Molded Case | ||
| Family | EDB Series | ||
| Amperage | 90 | ||
| Voltage | 480 | ||
| Poles | 3 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
EDB34090 Specifications:
Part NumberEDB34090
Manufacturers
Sub-CategoryMolded Case
FamilyEDB Series
TypeEDB
Weight3 lbs
Amperage90
Voltage480
Poles3
AIC Rating18kA@480V
FunctionsLI - Long-Time and Instantaneous
ProtectionThermal Magnetic
ConnectionBolt-On
Phase3
