MGN61307
MGN61307
IMAGES ARE FOR REFERENCE ONLY.
IMAGES ARE FOR REFERENCE ONLY.
Select Product Condition:
What's the difference?View Specifications
MGN61307 Specifications
View Full SpecificationsView Specifications
MGN61307, Schneider Electric, Square D, Multi9, type C60, UL listed, CSA certified, 1P, 1PH, 8A, 277V, 10kA@277V, standard interrupting capacity, Feed-Thru, C Curve 7-10 x ampere rating (7-14 for DC), single-barrel wire lug, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, Thermal Magnetic, molded case miniature circuit breakers, suitable for reverse feeding
| Manufacturer | Schneider Electric | Subcategory | Molded Case |
| Family | Multi9 | Amperage | 8 |
| Voltage | 277 | Poles | 1 |
| Manufacturer | Schneider Electric | ||
| Subcategory | Molded Case | ||
| Family | Multi9 | ||
| Amperage | 8 | ||
| Voltage | 277 | ||
| Poles | 1 |
Electrical.com is NOT an authorized distributor for Square D and therefore the manufacturer’s warranty does not apply. This product does include an Electrical.com 2 year warranty.
